General Specs |
| Product Weight (lbs.) | 40 |
| Color | Stainless Steel |
| Appliance Fit Width (cm.) | 76 |
| Element Type | Ribbon Radiant |
| Fuel Type | Electric |
| Appliance Color | Stainless Steel |
| Depth (in.) | 21 |
| Height (in.) | 5.56 |
| Width (in.) | 29.88 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Appliance Fit Width (in.) | 30 |
| Color Finish Name | Stainless Steel on Black |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Commercial Use Approved | No |
| Smart Compatible | No |
| Number of Elements/Burners | 5 |
| Width (cm) | 75.9 |
| Height (cm.) | 14.12 |
| Depth (cm.) | 53.34 |
| Voltage | 208/240 |
| Frequency | 60 |
| Amp | 40 |
| Product Weight (kg) | 18.14 |
| Cooktop Surface | Glass |
Features |
| Cooktop Burner Type | Smoothtop |
| Control Location | Front Center |
| Control Type | Glide Touch |
| Cooktop Control Features | All-Off Control; Control Lock Capability; Custom Settings; Keep-Warm Setting; Kitchen timer; Melt Setting; Multi-element timer; Sync-Burners Capability |
| Melt Setting | Yes |
| Indicator Lights | 5 Hot Surface; Red; Setting Level Indicators; Surface Element "ON" |
| Timer | Yes |
| Filler trim kit | JXTR32B |
Appearance |
| Frame colour / Material | Stainless Steel |
Weights and Dimensions |
| Cabinet Width | 30 in |
| Cooktop Size | 30 in |
| Cutout Dimensions (Width x Depth) (In.) | 28-1/2 x 19-5/8 |
Power/Ratings |
| Max. Connected Load (kW) at 208V | 7.1 |
| Max. Connected Load (kW) at 240V | 9.5 |
| Max. Current Draw (Amps) at 208V | 34.3 |
| Max. Current Draw (Amps) at 240V | 39.6 |
| Recommended Circuit Breaker (Amps) at 208V | 40 |
| Recommended Circuit Breaker (Amps) at 240V | 40 |
